Scaffolding Accessories

Keywords: Scaffolding Accessories, steel prop, Base Jack, Ladder Beam
Size: Scaffolding Prop:400*1829mm,400*2048mm,480*1289mm,480*2048mm or as your request.Base Jack:400*1829mm,400*2048mm,480*1289mm,480*2048mm or as your request Ladder Beam:Length: 3.353m (11') Weight: 25kg.Length: 4.877m(16') Weight: 45kgLength: 6.400m (21') Weight: 65kg.
Standard & Grade: GB 15831, EN 39, EN 10219, BS 1139, BS 1387-1985, JIS G 3444
Surface Treatment : Hot Dip Galvanized,Dip Painted,Galvanized
Delivery: Within 30 days and Depends on your order quantity.
Payment: TT, LC , OA , D/P
Packing: in bulk or steel pallet or as your request
Availability:
Inquire

Product Description

1. Simple structures, simple erection

2. High efficiency with strong loading capacity

3. With galvanized surface(endurable)

4. Widely application in propping system such as construction, plant

Steel prop


Product Details

NameScaffolding Prop
Place of OriginTianjin China
Brand nameShinestar
Size400*1829mm,400*2048mm,480*1289mm,480*2048mm or as your request
Main MaterialQ235 steel
Surface TreatmentHot Dip Galvanized,Dip Painted,Galvanized
ColorSilver
CertificateSGS ,CE
ServiceOEM Service available
Delivery TimeAbout 20-30 days after confirmation
Packingin bulk or steel pallet or as your request
production capability100 tons per day
Manufactory LocationTianjin, China


Base Jack

NameScaffold plank
Place of OriginTianjin China
Brand nameWorld
Size400*1829mm,400*2048mm,480*1289mm,480*2048mm or as your request
Main MaterialQ235 steel
Surface TreatmentHot Dip Galvanized,Dip Painted,Galvanized
ColorSilver
CertificateSGS ,CE
ServiceOEM Service available
Delivery TimeAbout 20-30 days after confirmation
Packingin bulk or steel pallet or as your request
production capability100 tons per day
factory LocationTianjin, China


Ladder Beam

1. Material: Q235, Q345

2. Advantage: antirust, skid proof

3. Surface treatment: painted or galvanized

4.Length: 3.353m (11′) Weight: 25kg

Length: 4.877m(16′) Weight: 45kg

Length: 6.400m (21′) Weight: 65kg

(Other lengths can be supplied to order).

5.Ladder Beam – safe load table

Span (m)UDL on top chordCentre point load
3.0529.9kN1 8.9kN
4.5724.2kN1 5.2kN
6.1017.6kN10.4kN

6.OEM service

7.EN74, BS1139, ISO9001:2000

8.quick to install, save in time and labor

9.we can do as customer`s need.



Base Jack

Name

Type

Size


Screw rod(mm)

Base Plate(mm)

Adjustable Base Jack

Solid

30 x 400

120 x 120 x 5


30 x 600

120 x 120 x 5


32 x 400

120 x 120 x 5


32 x 600

120 x 120 x 5


34 x 400

120 x 120 x 5


34 x 600

120 x 120 x 5


35 x 400

150 x 150 x 5


35 x 500

150 x 150 x 5


35 x 600

150 x 150 x 5


38 x 500

150 x 150 x 5


38 x 750

150 x 150 x 5


45 x 400

150 x 150 x 5


45 x 500

150 x 150 x 5


45 x 600

150 x 150 x 5

Adjustable Base Jack

Hollow

35 x 4 x 600

150 x 150 x 5


38 x 4 x 600

150 x 150 x 5


48 x 4 x 600

160 x 160 x 6


35 x 5 x 400

150 x 150 x 5


35 x 5 x 500

150 x 150 x 5


35 x 5 x 600

150 x 150 x 5


38 x 5 x 500

150 x 150 x 5


38 x 5 x 750

150 x 150 x 5


45 x 5 x 400

150 x 150 x 5


45 x 5 x 500

150 x 150 x 5


45 x 5 x 600

150 x 150 x 5

Adjustable U-head Jack

Solid

30 x 400

150 x 120 x 50 x 5


30 x 600

150 x 120 x 50 x 5


32 x 400

150 x 120 x 50 x 5


32 x 600

150 x 120 x 50 x 5


34 x 400

150 x 120 x 50 x 5


34 x 600

150 x 120 x 50 x 5


38 x 500

150 x 120 x 50 x 5


38 x 750

150 x 120 x 50 x 5


Ladder Beam

Name No. Length(mm) Width(mm) Weight(kg) Surface
Stair Case WD-SL2566 2566 442 19.5 HDG
WD-SL2677 2677 442 22.4 HDG
WD-SL2710 2710 442 22.55 HDG
WD-SL2860 2860 442 25.96 HDG
WD-SL2677 2677 442 22.9 HDG
WD-SL2710 2710 442 23 HDG
WD-SL2860 2860 442 26.58 HDG



steel prop

MarketplaceAdjustable DistanceOuter Pipe (mm)Inner Pipe (mm)
 Closed(mm)Opened(mm)
Spanish 800 1400 Φ48×1.6×765 Φ40×1.8×835
 1600 3000 Φ48×1.6×1600 Φ40×1.8×1600
 2000 3500 Φ48×1.6×1750 Φ40×1.8×2000
 2200 4000 Φ48×1.6×2000 Φ40×1.8×2200
Italian 1600 2900 Φ56×1.6×1524 Φ48×1.8×1600
 1800 3100 Φ56×1.6×1524 Φ48×1.8×1800
 2000 3600 Φ56×1.6×1750 Φ48×1.8×2000
22004000Φ56×1.6×2024 Φ48×1.8×2200
 German 1400 2700 Φ60×3.0×1396 Φ48×3.2×1400
 1600 3000 Φ60×3.0×1550 Φ48×3.2×1600
 1620 2640 Φ60×3.0×1396 Φ48×3.2×1610
20003500Φ60×3.0×1900Φ48×3.2×2000
Middle East22004000Φ60×3.0×1900Φ48×3.2×2200
30005500Φ60×3.0×2680Φ48×3.2×2900



Painted, Powder Painted, Electric Galvanized, Hot dipped Galvanized
